Excavator Mounted Pile Driver (Vibro Hammer)

OVR 120 S

OVR 120 S Isometric View Wireframe Technical Drawing

OVR 120 S Isometric View Technical Drawing

OVR 120 S Front View Technical Drawing

OVR 120 S Side View Wireframe Technical Drawing

OVR 120 S Side View Technical Drawing

OVR 120 S Back Side View Technical Drawing

TECHNICAL SPECIFICATIONS

Eccentric Moment (kgm) 12,3
Centrifugal Force (kN) Max.838
Power (kW) Max.167
Weight and Dimensions
Total Weight W/O Clamp (kg)1798
Length / L1 (mm)1487
Height / H1 (mm)1842
Width / W1 (mm)842

Recommended Clamps & Excavator

Clamp Type for Sheet Piles

Clamp Type for Casing

Recommended Excavator Working Weight

40-50

  • Fast, reliable and easy excavator connection,
  • Ergonomic design providing practical use,
  • Full safe movement around link yoke,
  • High performance and driving extracting power,
  • Minimum vibration transmission to the environment,
  • Pipe pile driving capability with sliding caisson type clamp system,
  • Powerful, reliable and long life.
