Complementary Products
Recommended Hydraulic Clamps
Suitable for near historical buildings to use with variable (resonance – free) models.
Advantages
Environmentally friendly technology, Controlled amplitude by means of adjustable eccentric moment, Resonance – free start – stop, Optimum force application to the ground via variable moment feature, Minimized sound transmission through high-capacity anti-vibration mounts, Powerful, reliable and long life.
Technical Specifications
| Eccentric Moment | 0 – 30 kgm |
| Centrifugal Force | 1746 kN |
| Power | 448 kW |
| Total Weight W/O Clamp | 5700 kg |
| Length / L1 | 2210 mm |
| Height / H1 | 2460 mm |
| Width / W1 | 388 mm |
| Eccentric Moment | 0-2603 in/lbs |
| Centrifugal Force | 197 tons |
| Power | 601 hP |
| Total Weight W/O Clamp | 12566 lbs |
| Length / L1 | 87 in |
| Height / H1 | 97 in |
| Width / W1 | 15 in |
Resonance Free Vibro Hammer Applications
Other Resonance Free Vibro Hammers
