Suitable for near historical buildings to use with variable (resonance – free) models.
Advantages
Environmentally friendly technology, Controlled amplitude by means of adjustable eccentric moment, Resonance – free start – stop, Optimum force application to the ground via variable moment feature, Minimized sound transmission through high-capacity anti-vibration mounts, Powerful, reliable and long life.
Technical Specifications
| Eccentric Moment | 0 – 24 kgm |
| Centrifugal Force | 1370 kN |
| Power | 394 kW |
| Total Weight W/O Clamp | 4523 kg |
| Length / L1 | 2060 mm |
| Height / H1 | 2115 mm |
| Width / W1 | 388 mm |
| Eccentric Moment | 0-2083 in.lbs |
| Centrifugal Force | 154 tons |
| Power | 529 hP |
| Total Weight W/O Clamp | 9972 lbs |
| Length / L1 | 81 in |
| Height / H1 | 83 in |
| Width / W1 | 15 in |
