Complementary Products
Recommended Hydraulic Clamps
Suitable for near historical buildings to use with variable (resonance – free) models.
Advantages
Environmentally friendly technology, Controlled amplitude by means of adjustable eccentric moment, Resonance – free start – stop, Optimum force application to the ground via variable moment feature, Minimized sound transmission through high-capacity anti-vibration mounts, Powerful, reliable and long life.
Technical Specifications
| Eccentric Moment | 0 – 20 kgm |
| Centrifugal Force | 1166 kN |
| Power | 292 kW |
| Total Weight W/O Clamp | 4280 kg |
| Length / L1 | 2060 mm |
| Height / H1 | 2115 mm |
| Width / W1 | 388 mm |
| Eccentric Moment | 0-1736 in/lbs |
| Centrifugal Force | 131 tons |
| Power | 392 hp |
| Total Weight W/O Clamp | 9436 lbs |
| Length / L1 | 81 in |
| Height / H1 | 83 in |
| Width / W1 | 15 in |
Resonance Free Vibro Hammer Applications
Other Resonance Free Vibro Hammers
