SCN 350 Hydraulic Clamp for Sheet Piles

Ideal for driving or extracting sheet piles.

Hydraulic clamps are manufactured from specially alloyed cast steel and feature two gripping jaws. One of these jaws is “fixed” while the other is “movable.” The hydraulic clamp includes a hydraulic cylinder that closes the movable jaw with a clamping pressure of up to 350 bar.

The jaws open and close by pressing the “clamp open/close” button on the remote control. The clamping and releasing process is completed within a few seconds.

Advantages

  • Ideal for driving and extracting sheet piles.
  • Equipped with a chain for securely holding and easily lifting sheet piles.
  • Designed for easy installation and ergonomic operation.

Technical Specifications

Clamping Force3560 kN
Weight2560 kg
Working Pressure350 bar
Length / L1343 mm
Width / W460 mm
Height / H1134 mm
Clamping Force400 tons
Weight5710 lbs
Working Pressure5076 psi
Length / L53 in
Width / W18 in
Height / H45 in
Download Flyer

Other SCN Series Hydraulic Clamps
