OMS Power Units can be controlled via the main control panel and instant information in relation to the hydraulic system, engine and retrospective failure logging can be obtained.
Advantages
Touch Screen Control Panel
Predicts Possible Failures
Enable to Self-Reprogramming
Powerful, Reliable and Long life
Technical Specifications
Engine Model (Option 1) Volvo TAD853VE (Stage IIIA / Tier 3) Engine Model (Option 2) Volvo TAD884VE (Stage V / Tier 4f) Power 235 kW Weight (Option 1) 5200 kg Weight (Option 2) 5300 kg Oil Flow Max. 460 lpm Pressure Max. 350 bar Oil Capacity 500 liter Diesel Tank Capacity 650 liter Width (W) 1660 mm Length (L) 4230 mm Height (H) 1750 mm
Engine Model (Option 1) Volvo TAD853VE (Stage IIIA / Tier 3) Engine Model (Option 2) Volvo TAD884VE (Stage V / Tier 4f) Power 320 hP Weight (Option 1) 11461 lbs Weight (Option 2) 11681 lbs Oil Flow Max. 121 gpm Pressure Max. 5076 psi Oil Capacity 132 gal Diesel Tank Capacity 171 gal Width (W) 65 in Length (L) 167 in Height (H) 69 in
