Suitable for near historical buildings to use with variable (resonance – free) models.
Advantages
Environmentally friendly technology, Controlled amplitude by means of adjustable eccentric moment, Resonance – free start – stop, Optimum force application to the ground via variable moment feature, Minimized sound transmission through high-capacity anti-vibration mounts, Powerful, reliable and long life.
Technical Specifications
| Eccentric Moment | 0 – 8 kgm |
| Centrifugal Force | 464 kN |
| Power | 103 kW |
| Total Weight W/O Clamp | 1650 kg |
| Length / L1 | 1280 mm |
| Height / H1 | 1680 mm |
| Width / W1 | 255 mm |
| Eccentric Moment | 0 – 695 inlbs |
| Centrifugal Force | 52 tons |
| Power | 138 hp |
| Total Weight W/O Clamp | 3637 lbs |
| Length / L1 | 50 in |
| Height / H1 | 66 in |
| Width / W1 | 10 in |
