SVR 80 NF Technical Specifications
Crane-Suspended Pile Driving Machine
Advantages of the SVR 80 NF Vibratory Hammer:
- High performance,
- Desired power settings and job tracking carried out by the control system,
- Various clamp types suitable for all pile profiles,
- Innovative design that adapts to rapidly evolving technology,
- Time and cost savings,
- 24/7 technical service and spare parts support,
- Powerful, reliable and long-lasting.
TECHNICAL SPECIFICATIONS
| Eccentric Moment (kgm) | 82.6 |
| Centrifugal Force (kN) | 1988 |
| Power (kW) | 559 |
| Weight & Dimensions | |
| Total Weight Excl. Clamps (kg) | 10257 |
| Length / L1 (mm) | 3315 |
| Height / H1 (mm) | 2200 |
| Width / W1 (mm) | 451 |
| Eccentric Moment (in.lbs) | 7170 |
| Centrifugal Force (ton) | 223 |
| Power (hP) | 750 |
| Weight & Dimensions | |
| Total Weight Excl. Clamps (lbs) | 22613 |
| Length / L1 (in) | 131 |
| Height / H1 (in) | 87 |
| Width / W1 (in) | 18 |
Recommended Clamps & Power Source
Clamp for Sheet Piles and Piles
Clamp Type for Casing
Recommended Power Package
